Products
- Scanprobe Camera Systems |
|
| |
| Mini Supercam Video Pipe Inspection System |
| The portable video pipe inspection system is for pipes from 30mm diameter upwards. The kit consists of a waterproof 22m dia colour CCD camera with a field view of 60 degrees and 8 LED’s; A high resolution 7” LCD monitor – with memory card function for video and image recording. A 40m reel of fibreglass cable, internal battery, AC/DC power supply and is integrated in a heavy duty plastic carrying case. Now with a keyboard for text generation and microphone for audio recording. |
|
 |
| |
| Colourprobe 3001 Crawler Pan & Tilt Pipeline Inspection System |
| Colourprobe 3001 Crawler Pan & Tilt Pipeline Inspection System Pan & tilt inspection system for surveying pipes from 150 - 1000mm, DVR records onto USB memory drive, 110 - 240volt mains or generator, 200 metre cable as standard (additional lengths available to order), text and on-screen meterage with optional inclinometer module for gradient measurement. (This is a complete system). |
|
 |
| |
A high performance system suitable for pipe sizes over 50mm up to 300mm Ø.
This system consists of a detachable 50mmØ auto self-levelling colour camera - with a ring of long life, high intensity white LED ighting; a range of centreing skids and a robust coiler frame - with 50m of 11mm semi-rigid push rod. This connects to a Scanprobe Compact Control Box - a rugged military spec box that has an integrated 10.5" flat screen monitor and touch pad controls and records directly on to portable memory USB drive, or an optional Hard Drive. The system comes complete with on-screen meterage, probewriter 16-page text generator and will ooperate at 110v or 240v AC - with auto switching - and also 24v DC with integrated rechargeable batteries for use where no mains power is available. |
|
 |
|
|
The baby brother to the Series 6 and 7 systems, but with the same robust design.
Suitable in pipe sizes from 40mm up to 225mmØ. This system consists of a detachable 35mm high resolution bullet colour camera head - with scratch proof sapphire lens glass; high intensity, white LED lighting; a range of centring skids and a robust coiler frame - with 50m of 11mm semi-rigid push rod. This connects to a Scanprobe Compact Control Box - a rugged military spec box that has an integrated 10.5" flat screen monitor and touch pad controls and records directly on to portable memory USB drive, or an optional Hard Drive. The system comes complete with on-screen meterage, probewriter 16-page text generator and will operate at 110v or 240v AC - with auto switching - and also 24v DC with integrated rechargeable batteries for use where no mains power is available. |
|
 |
| |
A heavy-duty CCTV inspection system that is designed to survey from a single access point in pipe sizes over 50mm up to 600mm Ø.
This system is fully loaded and consists of a detachable 50mmØ auto self-levelling colour camera - with a ring of long life, high intensity white LED lighting and external light head for larger diameter pipes; a range of centreing skids and a series of adjustable wheeled camera carriers and connects to 75m of 14mm semi-rigid push rod housed in a large robust coiler frame. This in turn, connects to a Scanprobe Compact Compact Control Box - a rugged military spec box that has an integrated 10.5" flat screen monitor and touch pad controls and records directly on to portable memory USB drive, or an optional Hard Drive. The system comes complete with on-screen meterage, probewriter 16-page text generator and will operate at 110v or 240v AC - with auto switching - and also 24v DC with integrated rechargeable batteries for use where no mains power is available. |
|
 |
| |
| Telescopic Drain Camera Inspection System 3.5" LCD |
| Portable telescopic video system allowing inspections of those hidden issues and hard to reach places such as guttering, manholes and ceilings. |
|
 |
| |
| Wireless Inspection Camera |
| The wireless inspection camera is a lightweight, ergonomic, handheld visual inspection system
for those hard to reach areas. The kit consists of a mini waterproof 22mmØ camera - that
has a night vision range of 1.5m; 1m of flexible extension shaft - with an option of adding x 5
additional 1m extension shafts; a 2.5" TFT-LCD wireless monitor with rechargeable Li-battery
and power supply; 3 useful accessories - hook, mirror and magnet. Records onto SD Card. |
|
 |
| |
A portable, manual winch for use with the Scanprobe Hydro-Cutter, and other pipeline inspection systems, within pipelines.
The Scanprobe Winch comes with two drive ratios, one enables retrieval with a 1:1 ratio and the other is a 2.5:1 for more precision positioning.
There is a locking ratchet mechanism allowing the cutter or robot to firmly locked in position in the sewer whilst carrying out operations.
|
|
 |
| |
Designed for easy use with Scanprobe camera systems.
Accurate and reliable, the user can trace the path of the
pipe from above ground - using a hand-held receiver - to
determine the position and depth of the Sonde transmitter
when it has reached a problem inside a pipe - all at the
push of a button.
Two versions of the transmitter are available: The
integrated version, that connects directly behind the
camera head and is powered by the Scanprobe System;
and the Self-Powered version with an independent battery
powered unit that is fixed to - and positioned by - standard
Drain Rods (optional extra)
*Compatible with the Bullet 35, Series
6 and Series 7 Only
|
|
 |
|
|
